TINI DW MULTI-SWITCH – SERIES 90000 & 92000
PHONE: 773 792-2700
312
SWITCHES
?
* Please visit the product pages on our website for the most up-to-date product information
MULTIPLE-STATION SWITCHES (continued)
SERIES 92000 Switch TDW-F
Flip-Flop Pushbutton Installed
SERIES 90000 with
A-650 Pushbuttons Installed
TINI ? DW MULTI-SWITCH – SERIES 90000, 92000
Subminiature, multiple station switches have pushbuttons on
0.394" (10mm), 0.590" (15mm), or 0.787" (20mm) centers.
Four mechanical functions: Interlock, Non-Lock, All-Lock and
Push-Lock/Push-Release. Switches mount in panels up to
.343" (8.71mm) thick. Switching per station is 2-C (2PDT),
4-C (4PDT), 6-C (6PDT) or 8-C (8PDT). Contact ratings: 0.5A,
28V AC or DC non-inductive. Solder lug or PC terminals.
SERIES 90000 - Up to 18 stations on 0.394" (10mm) centers
Pushbuttons for Tini DW Multi-Switch switches must be specified
separately, below. Refer to page 316 for data on TWDF pushbuttons.
Series A650 pushbuttons can be specified for both Series
90000 and 92000. Legends can be specified; contact
Switchcraft.
PART NUMBERS/2-C PER STATION 1
in a row. Switch mounts with 2, #3 screws (not supplied).
Interlock
Push-Lock/
Number of
SERIES 92000 - 15mm station centers. Wider spacing
permits mounting Series TDWF pushbuttons.
SPECIFICATIONS
ELECTRICAL
Switching Module Rating: 0.5A, 28V AC or DC
non-inductive load.
Initial Contact Resistance: 10 milliohms.
with Lock-Out
? 90024B06
? 90044B06
? 90064B06
? 90084B06
? 90104B06
? 90124B06
Non-Lock
? 90022B06
? 90042B06
? 90062B06
? 90082B06
? 90102B06
? 90122B06
Push-Release
? 90027B06
? 90047B06
? 90067B06
? 90087B06
? 90117B06
? 90127B06
Stations 2
2
4
6
8
10
12
MATERIALS
PART NUMBERS/4-C PER STATION 1
Frame Switch Housing: Steel, plated.
Latch Bar: Stainless steel on all-lock function;
zinc alloy on interlock function.
Latch Bar Return Spring: Tinned music wire.
Plunger: Molded thermoplastic.
Plunger Return Spring: Tinned music wire.
? 90024B12
? 90044B12
? 90064B12
? 90084B12
? 90104B12
? 90124B12
? 90022B12
? 90042B12
? 90062B12
? 90082B12
? 90102B12
? 90122B12
? 90027B12
? 90047B12
? 90067B12
? 90087B12
? 90117B12
? 90127B12
2
4
6
8
10
12
Terminals/Contacts: Copper alloy, silver-plated.
Contact Sliders: Bifurcated bimetal (silver on copper alloy).
Terminal Board: Molded thermoplastic (UL 94V-0).
Pushbuttons: Molded thermoplastic.
PUSHBUTTONS
1 Switches with all-lock function are available on special order. Contact Switchcraft.
2 Odd number of stations (3, 5, 7, 9, 11) are available. Switches with 13 through
18 stations also available. Contact Switchcraft.
? Special order only; Contact Switchcraft for price and delivery information.
SPECIFYING NOTE:
Series 90000 Part Numbers are given in table. To order Series
92000 switches, substitute “2” for “0” for second digit of Part
Part Number
? A6501
? A6502
? A6503
Color
Red
Black
Green
Part Number
? A6504
? A6505
? A6508
Color
Blue
White
Yellow
Number. Example; Part Number 92024B06 in the Series
92000 version 0.590" (15mm centers) of Part Number
90024B06 0.394" (10mm centers) interlock with lock-out, 2-C
switching per station.
Buttons are 0.386 (9.80 mm) x 0.386 (9.80 mm).
? Special order only; Contact Switchcraft for price and delivery information.
DIMENSIONS ARE FOR REFERENCE ONLY
www.switchcraft.com
Inch
(mm)
? Registered trademark of Switchcraft, Inc.
Note: Contact your Switchcraft Representative for price and delivery
